Product Details:
|
| Peak Power: | 450W | Peak Power Voltage: | 450V |
|---|---|---|---|
| Peak Power Current: | 22% | Open-circuit Voltage: | 10.89A |
| Short-circuit Current: | 49.90A | Power Output: | 11.47A |
| Weight: | 23.5KG | Size: | 2094*1038*35mm |
| Highlight: | 450W Monocrystalline Silicon Solar Panel,550W Monocrystalline Silicon Solar Panel |
||
| Peak Power | Pmax (W) | 435 | 440 | 445 | 450 |
| Peak Power Voltage | Vmp(V) | 40.75 | 40.95 | 41.15 | 41.35 |
| Peak Power Current | Imp(A) | 10.68 | 10.75 | 10.82 | 10.89 |
| Open-circuit Voltage | Voc(V) | 49.30 | 49.50 | 49.70 | 49.90 |
| Short-circuit Current | Isc(A) | 11.26 | 11.33 | 11.40 | 11.47 |
| Pnactical Module efficiency | (%) | 16.6 | 16.9 | 17.2 | 17.5 |
| Production Tolerance | (W) | 0～+5W | |||
*STC: Irradiance1000W/m, Battery Temperature25℃,SpectrumAM1.5.
| Maximum Power | Pmax (W) | 322.2 | 326.0 | 329.7 | 333.4 |
| Maximum power operating voltage | Vmp(V) | 37.7 | 37.9 | 38.1 | 38.3 |
| Maximum power operating current | lmp(A) | 8.54 | 8.60 | 8.66 | 8.71 |
| Open-circuit Voltage | Voc(V) | 46.0 | 46.2 | 46.3 | 46.5 |
| Short-circuit Current | Isc(A) | 9.12 | 9.17 | 9.23 | 9.29 |
Best QC System
Product packaging
Technical Support and Service for Photovoltaic PV Solar Panels
We are committed to providing our customers with quality technical support and service for Photovoltaic PV Solar Panels. Our team of professionally trained technicians is available to assist you in any way possible.
In addition to these services, we also provide replacement parts and accessories for our Photovoltaic PV Solar Panels. We guarantee that our products are of the highest quality and will last for years to come.
For more information about our technical support and service for Photovoltaic PV Solar Panels, please contact us at your convenience.
